RAG Systems Deep Dive Part 4: Building the Web Interface

In Part 3, we enhanced our RAG system with hybrid search, streaming, and caching. Now, let’s build a polished web interface to showcase these features using Next.js and modern React patterns.

1. Project Setup

If you’re starting fresh, create a new Next.js project:

npx create-next-app@latest rag-ui --typescript --tailwind --eslint
cd rag-ui
npm install @langchain/openai @langchain/community langchain lucide-react @radix-ui/react-progress

We’ll use the shadcn/ui component library for a polished look. Install it following their setup guide:

npx shadcn-ui@latest init

Install the components we’ll need:

npx shadcn-ui@latest add button card progress textarea alert

2. Building the Chat Interface

Let’s create a clean, responsive chat interface that supports:

Real-time streaming responses
Source attribution
Loading states
Error handling

Create app/components/chat.tsx:

'use client';

import { useState } from 'react';
import { Card } from '@/components/ui/card';
import { Button } from '@/components/ui/button';
import { Textarea } from '@/components/ui/textarea';
import { Progress } from '@/components/ui/progress';
import { Alert, AlertTitle, AlertDescription } from '@/components/ui/alert';
import { Send, Loader2 } from 'lucide-react';

interface Message {
  role: 'user' | 'assistant';
  content: string;
  sources?: Array<{
    text: string;
    score: number;
    type: 'vector' | 'keyword';
  }>;
}

export function Chat() {
  const [messages, setMessages] = useState<Message[]>([]);
  const [input, setInput] = useState('');
  const [isLoading, setIsLoading] = useState(false);
  const [error, setError] = useState<string | null>(null);

  async function handleSubmit(e: React.FormEvent) {
    e.preventDefault();
    if (!input.trim() || isLoading) return;

    const question = input.trim();
    setInput('');
    setError(null);
    setIsLoading(true);

    // Add user message immediately
    setMessages(prev => [...prev, { role: 'user', content: question }]);

    try {
      const response = await fetch('/api/chat', {
        method: 'POST',
        headers: { 'Content-Type': 'application/json' },
        body: JSON.stringify({ question }),
      });

      if (!response.ok) throw new Error('Failed to fetch response');

      const reader = response.body?.getReader();
      if (!reader) throw new Error('No response body');

      // Prepare for streaming
      let assistantMessage = '';
      setMessages(prev => [...prev, { role: 'assistant', content: '' }]);

      // Read the stream
      while (true) {
        const { done, value } = await reader.read();
        if (done) break;

        // Decode and append the chunk
        const chunk = new TextDecoder().decode(value);
        assistantMessage += chunk;

        // Update the last message
        setMessages(prev => [
          ...prev.slice(0, -1),
          { role: 'assistant', content: assistantMessage }
        ]);
      }
    } catch (err) {
      setError(err instanceof Error ? err.message : 'An error occurred');
    } finally {
      setIsLoading(false);
    }
  }

  return (
    <div className="container max-w-4xl mx-auto p-4">
      <Card className="mb-4">
        <div className="h-[600px] overflow-y-auto p-4 space-y-4">
          {messages.map((message, i) => (
            <div
              key={i}
              className={`flex ${
                message.role === 'user' ? 'justify-end' : 'justify-start'
              }`}
            >
              <div
                className={`rounded-lg px-4 py-2 max-w-[80%] ${
                  message.role === 'user'
                    ? 'bg-blue-500 text-white'
                    : 'bg-gray-100'
                }`}
              >
                {message.content}
                {message.sources && (
                  <div className="mt-2 text-sm opacity-75">
                    {message.sources.map((source, i) => (
                      <div key={i} className="mt-1">
                        Source {i + 1}: {source.type} match (score: {source.score})
                      </div>
                    ))}
                  </div>
                )}
              </div>
            </div>
          ))}
          {isLoading && (
            <div className="flex justify-center">
              <Loader2 className="h-6 w-6 animate-spin" />
            </div>
          )}
        </div>

        <form onSubmit={handleSubmit} className="p-4 border-t">
          <div className="flex gap-2">
            <Textarea
              value={input}
              onChange={(e) => setInput(e.target.value)}
              placeholder="Ask a question..."
              className="flex-1"
              rows={1}
            />
            <Button type="submit" disabled={isLoading}>
              {isLoading ? (
                <Loader2 className="h-4 w-4 animate-spin" />
              ) : (
                <Send className="h-4 w-4" />
              )}
            </Button>
          </div>
        </form>
      </Card>

      {error && (
        <Alert variant="destructive">
          <AlertTitle>Error</AlertTitle>
          <AlertDescription>{error}</AlertDescription>
        </Alert>
      )}
    </div>
  );
}

3. API Implementation

Let’s create the API endpoint that connects our UI to the RAG system. Create app/api/chat/route.ts:

import { NextRequest, NextResponse } from 'next/server';
import { StreamingTextResponse, LangChainStream } from 'ai';
import { loadDocuments } from '@/lib/document-loader';
import { createEnhancedQueryEngine } from '@/lib/enhanced-query';

// Initialize the query engine
let queryEngine: any = null;

async function initializeEngine() {
  if (queryEngine) return queryEngine;

  console.log('Initializing query engine...');
  const documents = await loadDocuments();
  queryEngine = await createEnhancedQueryEngine(documents);
  return queryEngine;
}

export async function POST(req: NextRequest) {
  try {
    const { question } = await req.json();

    // Initialize engine if needed
    const engine = await initializeEngine();

    // Create a streaming response
    const { stream, handlers } = LangChainStream();

    // Process the query
    engine.stream(
      { question },
      { callbacks: handlers }
    );

    // Return the stream
    return new StreamingTextResponse(stream);

  } catch (error) {
    console.error('Chat API error:', error);
    return NextResponse.json(
      { error: 'Failed to process query' },
      { status: 500 }
    );
  }
}

4. Page Integration

Update app/page.tsx to use our chat component:

import { Chat } from './components/chat';

export default function Home() {
  return (
    <main className="min-h-screen bg-gray-50 py-12">
      <div className="container max-w-4xl mx-auto px-4">
        <h1 className="text-3xl font-bold text-center mb-8">
          RAG-Powered Research Assistant
        </h1>
        <Chat />
      </div>
    </main>
  );
}

5. Advanced Features

5.1 Source Attribution Component

Create a component to display document sources with relevance scores. Create app/components/source-card.tsx:

import { Card } from '@/components/ui/card';

interface SourceInfo {
  content: string;
  score: number;
  method: 'vector' | 'keyword';
}

export function SourceCard({ sources }: { sources: SourceInfo[] }) {
  return (
    <Card className="mt-2 p-3 bg-gray-50">
      <h3 className="text-sm font-medium mb-2">Sources:</h3>
      <div className="space-y-2">
        {sources.map((source, index) => (
          <div key={index} className="text-sm">
            <div className="flex items-center gap-2">
              <span className={`px-2 py-0.5 rounded text-xs ${
                source.method === 'vector'
                  ? 'bg-blue-100 text-blue-700'
                  : 'bg-green-100 text-green-700'
              }`}>
                {source.method}
              </span>
              <span className="text-gray-500">
                Score: {source.score.toFixed(2)}
              </span>
            </div>
            <p className="mt-1 text-gray-700">{source.content}</p>
          </div>
        ))}
      </div>
    </Card>
  );
}

5.2 Error Boundary

Create app/components/error-boundary.tsx:

'use client';

import { Component, ErrorInfo, ReactNode } from 'react';
import { Alert, AlertTitle, AlertDescription } from '@/components/ui/alert';

interface Props {
  children?: ReactNode;
}

interface State {
  hasError: boolean;
  error?: Error;
}

export class ErrorBoundary extends Component<Props, State> {
  public state: State = {
    hasError: false
  };

  public static getDerivedStateFromError(error: Error): State {
    return { hasError: true, error };
  }

  public componentDidCatch(error: Error, errorInfo: ErrorInfo) {
    console.error('Uncaught error:', error, errorInfo);
  }

  public render() {
    if (this.state.hasError) {
      return (
        <Alert variant="destructive">
          <AlertTitle>Something went wrong</AlertTitle>
          <AlertDescription>
            {this.state.error?.message || 'An unknown error occurred'}
          </AlertDescription>
        </Alert>
      );
    }

    return this.props.children;
  }
}

6. Performance Optimizations

6.1 Response Caching

Implement a simple client-side cache for responses:

type CacheEntry = {
  response: string;
  timestamp: number;
};

class ResponseCache {
  private cache: Map<string, CacheEntry> = new Map();
  private readonly ttl: number = 1000 * 60 * 5; // 5 minutes

  set(question: string, response: string) {
    this.cache.set(question, {
      response,
      timestamp: Date.now()
    });
  }

  get(question: string): string | null {
    const entry = this.cache.get(question);
    if (!entry) return null;

    if (Date.now() - entry.timestamp > this.ttl) {
      this.cache.delete(question);
      return null;
    }

    return entry.response;
  }
}

export const responseCache = new ResponseCache();

6.2 Debounced Search

Add debouncing to prevent rapid-fire API calls:

import { useCallback } from 'react';
import debounce from 'lodash/debounce';

const debouncedSearch = debounce(async (question: string) => {
  // Your search logic here
}, 300);

// In your component:
const handleInputChange = useCallback((e: React.ChangeEvent<HTMLTextAreaElement>) => {
  setInput(e.target.value);
  debouncedSearch(e.target.value);
}, []);

7. Testing

Create __tests__/chat.test.tsx for component testing:

import { render, screen, fireEvent, waitFor } from '@testing-library/react';
import { Chat } from '../app/components/chat';

describe('Chat Component', () => {
  it('sends messages and displays responses', async () => {
    render(<Chat />);

    // Find input and submit
    const input = screen.getByPlaceholderText('Ask a question...');
    const submitButton = screen.getByRole('button');

    // Type and submit a message
    fireEvent.change(input, {
      target: { value: 'What are the recent developments?' }
    });
    fireEvent.click(submitButton);

    // Wait for response
    await waitFor(() => {
      expect(screen.getByText(/recent developments/i)).toBeInTheDocument();
    });
  });

  it('handles errors gracefully', async () => {
    // Mock failed API call
    global.fetch = jest.fn().mockRejectedValue(new Error('API Error'));

    render(<Chat />);

    const input = screen.getByPlaceholderText('Ask a question...');
    const submitButton = screen.getByRole('button');

    fireEvent.change(input, { target: { value: 'Test question' } });
    fireEvent.click(submitButton);

    await waitFor(() => {
      expect(screen.getByText(/error/i)).toBeInTheDocument();
    });
  });
});

Conclusion

This implementation provides a robust, user-friendly interface for our RAG system with:

Real-time streaming responses
Clean error handling
Source attribution
Performance optimizations
Comprehensive testing

The complete example demonstrates how to build a production-ready RAG interface that’s both functional and user-friendly.

In the next part, we’ll explore advanced topics like:

Multi-document support
Advanced caching strategies
Performance monitoring
Deployment considerations

Pedro Alonso

RAG Systems Deep Dive Part 4: Building the Web Interface

RAG Systems Deep Dive Series

1. Project Setup

2. Building the Chat Interface

3. API Implementation

4. Page Integration

5. Advanced Features

5.1 Source Attribution Component

5.2 Error Boundary

6. Performance Optimizations

6.1 Response Caching

6.2 Debounced Search

7. Testing

Conclusion

Related Articles

RAG Systems Deep Dive Part 3: Advanced Features and Performance Optimization

RAG Systems Deep Dive Part 1: Core Concepts and Architecture

RAG Systems Deep Dive Part 2: Practical Implementation with LangChain

Extending LLM Capabilities with Custom Tools: Beyond the Knowledge Cutoff

RAG Systems Deep Dive Series

1. Project Setup

2. Building the Chat Interface

3. API Implementation

4. Page Integration

5. Advanced Features

5.1 Source Attribution Component

5.2 Error Boundary

6. Performance Optimizations

6.1 Response Caching

6.2 Debounced Search

7. Testing

Conclusion

Get Your Free Developer Guide

Related Articles

RAG Systems Deep Dive Part 3: Advanced Features and Performance Optimization

RAG Systems Deep Dive Part 1: Core Concepts and Architecture

RAG Systems Deep Dive Part 2: Practical Implementation with LangChain

Extending LLM Capabilities with Custom Tools: Beyond the Knowledge Cutoff

Get Your Free Developer Guide
